4K60Hz HDMI USB3.2 Capture card Support 2K 144Fps, 1080P 240FPS
No items found.
In Stock
Strict Quality Control
1-Year Product Warranty
4K60Hz HDMI USB3.2 Capture card Support 2K 144Fps, 1080P 240FPS
$ 18.00 USD
Product Description
4K HDMI capture card with ultra-low latency, supports 4K@60Hz, HDR, VRR, Dolby Atmos, 3.5mm audio input, and USB 3.2 for seamless video/audio recording and streaming, compatible with PS5, Xbox, PC, and macOS, with CE, FCC, and ROHS certifications.
Package Content
1. 4K HDMI Video Capture Card x 1
2. USB3.0 Cable x 1
3. User Manual x 1
Weight
238
g
Dimensions
3.6
cm
x
14.5
cm
x
12.5
cm
Made in
China
SKU:
S-CA-4K-HUD
Thank you! Your submission has been received!
Oops! Something went wrong while submitting the form.
Tweet about #SYONG products
4K60Hz HDMI USB3.2 Capture card Support 2K 144Fps, 1080P 240FPS
UVC USB 3.2 out,4K@60FPS,2K@120/144FPS,1080P@60/120/144/240FPS
VRR,HDR 10,RGB 4:4:4/8:8:8
Audio Enjoyment,Dolby ATMOS,Dolby Digital Plus,DTS, DSD etc.
Color space:NV12,I420,YUY2 and MJPEG
Ultra-low Latency,3.5mm Audio & Mic* Unparalleled Compatibility,Windows 10 or higher,Mac OS X 10.10 or higher
Connect Game Console/Host,Input:PS5/4,XBox,Roku, PC,Laptop etc,Output: HDMI TVs, projectors, monitors.
Certified by CE,FCC & ROHS,One Year Free Warranty.
Buy with confidence, we have obtained the relevant certification to ensure safety and reliability.
4k@60HZ Pass-Through and Record: HDMI signal loop out supports HDR 4K 60HZ, supports 1080P 240Hz or 1440P 144Hz high frame rate pass-through to obtain smooth and realistic gameplay. recording 4K 60hz, can collect audio and video at the same time. enjoy fun when recording video. With the HDMI signal loop-out function, you can have fun with your friends while capturing video.
Support HDR / VRR function: Video Capture Card support 4K60FPS 1080P/240FPS while supporting HDR 12bit color depth image quality, VRR variable refresh rate for smoother live streaming images, and Plug and Play allows the device to be used immediately for streaming media such as OBS. Ideal for live broadcasting, game broadcasting, video recording, meeting rooms, etc.
Ultra-low Latency: The straight-through signal has ultra-low latency, so you can say goodbye to delays and interruptions during recording and video streaming. Ultra-low latency ensures a seamless, natural user experience when capturing video or playing games.
Better Recording and Streaming: Support USB 3.2 Faster transfer speed ,Synchronous recording of audio and video, live or record video with zero delay, smoother and clearer, and can use the functions built into the current software to get a seamless experience. It is perfect for live streaming, video recording, screen sharing, live conference, distance education and learning and so on.
3.5mm Audio Interface: The 3.5mm audio interface on the HDMI capture card allows you to connect directly to an analog audio source using a standard 3.5mm connector. This helps capture audio from devices such as microphones, headphones, line-level sources, or musical instruments without the need for additional converters or interfaces.
Specs
Maximum input resolution
4K@60Hz
Maximum Output resolution
4K@60Hz
Support video format
8/10/12bit Deep color
Video output format
YUV, JPEG
Support audio format
L-PCM
Input cable distance
≤15m, AWG26 HDMI standard cable
PC Hardware Interface
HDMI, USB3.2
Input Interface
HDMI
Support OS
Windows, Android, and Mac OS
Support Acquisition software
VLC, OBS, Amcap, etc.
USB Standard
USB Video Class (UVC) specification; USB video 1.5 and 1.0 standard
Max working current
0.4A/5VDC
Operating Temperature range
(-10 to +55°C)
Dimension (L x W x H)
64x28x13 (mm)
Weight
21.4g
A. Windows Computer Hardware Requirements (Need support UVC protocol)
A.1 MJPEG 4K60 Computer Hardware Requirements
Desktop
Intel Core i7-10XXX or above, NVIDIA GeForce GTX 1650 or above, 8GB RAM (2 Channels)
Notebook
Intel Core i9-9XXX or above, NVIDIA GeForce GTX 1650 or above, 8GB RAM (2 Channels)
A.2 NV12/I420 4K30 Computer Hardware Requirements
Desktop
Intel Core i5-6XXX or above, NVIDIA GeForce GTX 1060 or above, 8GB RAM (2 Channels)
Notebook
Intel Core i7-7700HQ or above, NVIDIA GeForce GTX 1050Ti or above, 8GB RAM (2 Channels)
